The key steps for installing rubber waterstop strips to ensure effective waterproofing are as follow

Specifications Verification: Confirm the strip type (e.g., water-swellable, embedded, external-mounted), dimensions (width/thickness), material (natural rubber/EPDM), and performance (swelling ratio ≥200% for water-swellable types, tensile strength ≥8MPa).

Visual Check: Reject strips with defects like cracks, uneven swelling layers, or damaged edges.

Storage Requirements: Store in a cool, dry place away from moisture (to prevent premature swelling) and chemicals; maintain temperatures between -5°C and 30°C.

Cleaning: Remove debris, dust, oil, and loose concrete from the installation groove or joint. Use a wire brush to roughen smooth surfaces for better adhesion.

Groove Preparation: For embedded strips, ensure the groove depth-width ratio is 1:1.5 (e.g., 20mm depth × 30mm width) to accommodate swelling and prevent extrusion.

Center Alignment: Place the strip along the joint centerline, ensuring continuous coverage without gaps. Use marking lines to guide placement.

Temporary Fixation: Secure the strip with waterproof adhesive or plastic anchors every 300–500mm to prevent displacement before concrete pouring or sealing.

Butt Joint with Overlap: For end connections, overlap strips by 50–100mm and bond with a special water-swellable rubber adhesive. Avoid lap joints in high-pressure areas.

Corner Treatment: At 90° corners, cut the strip at a 45° angle and reinforce with a 100×100mm patch to maintain continuity.

Avoid Moisture Exposure: Keep the strip dry before concrete pouring to prevent premature swelling. Cover with plastic film if rain is expected.

Concrete Vibration Caution: Keep vibrators ≥200mm away from the strip to avoid damage; pour concrete symmetrically around the strip to prevent displacement.

Base Coating: Apply a two-component polyurethane adhesive to the substrate, ensuring even coverage. Wait 5–10 minutes until the adhesive becomes tacky.

Strip Placement: Press the strip onto the substrate starting from the center, smoothing outward to eliminate air bubbles. Use a rubber roller to enhance adhesion.

Sealant Reinforcement: Apply a silicone or polyurethane sealant along the strip edges (width ≥8mm) to form a secondary waterproof layer, especially at terminations and penetration points.

Circular Sealing: Wrap the strip around the pipe (overlapping by 80–100mm), secure with a metal clamp, and fill gaps with water-swellable putty for a tight seal.

Pre-compression Installation: For joints with expected movement, install the strip in a pre-compressed state (using compression fixtures) to ensure continuous sealing as the joint expands/contracts.

Position and Continuity: Verify the strip is centered, free of wrinkles, and has no gaps (joint overlap ≥50mm). Check for missing fixation points.

Adhesion Test: Gently pull the strip’s edge; it should not detach from the substrate (adhesion strength ≥0.5MPa).

Moisture Exposure Test: For water-swellable strips, spray water on the installation site and monitor swelling (should expand uniformly within 24 hours without deformation).

Leakage Detection: After concrete curing, conduct a 48-hour dewatering test for underground structures; repair any seepage spots with additional sealant.

Installing water-swellable strips in wet conditions, causing premature swelling and reduced effectiveness.

Neglecting to clean the substrate, leading to poor adhesion and seepage paths.

Overstretching the strip during installation, which damages its molecular structure and reduces waterproof performance.
